Dynamic & Static Bend Stiffeners [BSR & DBS]
Introducing our high-performance BSR & DBSs, covering an outer diameter range of 25mm to 350mm and designed to withstand bending moments in excess of 50 kNm. Compliant with API 17 L1 / L2 standards, our offerings are crafted from durable polyurethane 85°A, ensuring a remarkable design life of up to 30 years. We provide both standard and bespoke designs, ready for quick delivery, with all products validated through rigorous analysis and factory acceptance testing. Fatigue testing and qualification services are also upon request to meet your specific needs.
Key features & Description:
​​
Product OD Range: 25mm to 350mm
Design Bending Moments: In excess of 50 kNm
Design Standard: API 17 L1 / L2
Material Selection: Polyurethane 85°A
Design Life: Up to 30-Years
Interface Material: BS EN 10025 : S355/SAE 316L/UNS S32750
​
Standard & bespoke designs are available, with a vast range of standard products ready to supply with short lead-times. All designs are validated through analysis (Orcaflex or other) & factory acceptance testing.
​​
​
​
​
.jpeg)
Testing
All BSR designs are type-tested to ensure that the equipment is suitable for operational use. Our BSRs are designed and produced based on our teams extensive experience of supplying the product type for a significant period.
